802138166 muzzle XCMG XS265 road roller spare parts

Short Description:

Muzzle is the pipe transition component for road‑roller hydraulic and pipeline system. It connects pipelines for medium circulation and ensures normal flow of hydraulic oil and coolant for conduction and limiting purpose.

Send email to us

Product Detail

Product Tags

description

Part number: 802138166
Part name: muzzle
Unit name: driver’s cab assy
Fit for XCMG road roller XS265, suitable for large‑scale subgrade, municipal road and site backfill compaction construction. Used to replace original muzzle with crack, thread damage and deformed end face.

Slipped thread, bumped deformed end face and cracked body will lead to oil leakage, water seepage and loose pipeline connection, resulting in insufficient system pressure and abnormal operation of vibration and travel system.

Number	Parts Name	Quantity	Material Encoding
1	SYRINGE	1	813505797
813503568	WASHER	1	813503568
2	MUZZLE	2	802138166
3	WIPER 24V	1	802141322
4	WORK LAMP	6	813501068
5	LED WARNING LIGHT	1	813505571
813502486	LED WARNING LIGHT	1	813502486
6	SPEAKER	2	803545939
7	RADIO	1	803810904
8	LED READING LIGHT	1	813502466
9	FUSE BOX WIRING	1	229000179
10	SWITCH	1	226803919
11	RECEIVER ANTENNA	1	802140676
12	WIPER	1	803754218
13	ELECTRIC FAN ASSY.	1
14	CAB HARNESS	1	227022898

=======================================

advantages

Thread specification, joint end‑face size and outer mounting dimension fully conform to original standard. Direct pipeline connection without extra processing.
High‑strength material features high pressure and impact resistance, withstand hydraulic pressure fluctuation and long‑term roller vibration, reduce crack‑and‑leakage risk.
High‑precision joint surface delivers good fitting sealing performance, effectively reduce medium leakage and keep stable pipeline system pressure.
Standard vulnerable pipeline part supports bulk stocking and fast on‑site replacement, cut maintenance downtime and meet spare‑parts stocking demand for overseas projects in Middle East and Africa.

maintenance & replacement

Shut down machine and release residual pipeline pressure before disassembly to avoid injury caused by high‑pressure medium ejection.
Clear sludge and iron scraps on thread to prevent valve jamming caused by impurities entering pipeline.
Tighten with standard torque. Violent over‑torque operation is forbidden to avoid thread stripping and body crack.
Start machine after installation and check oil leakage and water seepage at joint position.
Do not reuse after repair when body cracks, thread damages or end face is heavily bumped, replace muzzle directly.
