131401020698B042 Brake Sany SAT40C mining truck spare parts

Short Description:

131401020698B042 brake, core executive component for mining truck service brake. It generates braking torque by hydraulic drive to realize deceleration and parking, withstands heavy‑load bumping impact in mine site, guarantees safety during traveling and dumping operation.

Send email to us

Product Detail

Product Tags

description

Part number: 131401020698B042
Part name: Brake
Unit name: 131401020703B Middle Axle
Applicable Sany SAT40C mining truck

This brake fits Sany mining dump truck SAT40C. Mounting flange holes, oil‑port specifications and friction pair parameters fully conform to OEM parts without modification. Suitable for heavy‑load ore & muck transportation in open‑pit mine. It is used for replacement for weak braking, excessive friction‑pad wear, cylinder oil leakage and return jamming, meeting spare‑part supply for mining truck brake overhaul, on‑site maintenance and overseas second‑hand machine refurbishment.

*Due to the wide variety of products, the pictures displayed may not match the actual ones, and the part numbers are mainly used.

INDEX/ PART NO. /DESCRIPTION /Remark

150 131401020698B042 Brake
250 60062647 Brake Friction Disc
251 131401020698B014 Steel Piece
252 131401020698B043 Piston
253 60099227 Pipework
254 60099215 Socket Head Cap Screw
258 60223521 Oil Seal
259 60223522 Oil Seal
260 131401020698B044 Brake Carrier
261 131401020698B045 Brake Housing
262 131401020698B013 O-ring
263 60223634 O-ring
265 131401020698B019 O-ring
266 131401020698B046 Hexagon Head Screw
269 131401020698B047 Hexagon Screw
271 131401020698B012 Floating Oil Seal
272 60122004 Spiral Plug
273 60223579 Sealing Ring
278 60099198 Joint
279 60223578 Sealing Ring
280 60099160 Exhaust Valve
281 131401020698B015 Pipe

====================================================

advantages

High‑strength housing structure, resist mine heavy‑load impact, stable braking torque and good heat dissipation
Friction pads with proper wear coefficient for mining heavy‑duty condition, anti‑heat‑fade for long service life
High‑pressure & temperature‑resistant seal kit, adapt to dusty large‑temperature‑difference mine environment, reduce leakage risk
Interfaces and mounting dimensions fully match original truck for direct installation.

FAQ

Q:Can brake with slight housing leakage and usable braking function keep working?

A:Seals are aged, leakage will get worse, air ingress may cause soft brake failure. Very high risk under mine heavy‑load condition, replace brake promptly.
