228902317 drum XCMG XS265 road roller spare parts

228902317 drum XCMG XS265 road roller spare parts Featured Image
  • 228902317 drum XCMG XS265 road roller spare parts

Short Description:

Product advantages:

1. High -quality products.

2. Select high -quality materials.

3. More accurate matching size.

4. Reduce the risk of damage.

5. Factory sells directly, price discounts.

6. Complete Range of Spare Parts.


Product Detail

Product Tags

description

Part number: 228902317
Part name: drum
Unit name: drum assembly
Applicable Models: XCMG XS265 vibratory road roller

Number Parts Name Quantity Material Encoding
1 SHOCK ABSORBER 24 801902777
2 BOLT 63 805046640
805046639 BOLT 63 805046639
3 WASHER 12 102 805301374
4 NUT M12 48 805203168
805200098 NUT M12 48 805200098
5 BOLT M16×85 20 805047780
805000637 螺栓 M16×85 20 805000637
6 WASHER 16 20 805301377
7 NUT M16 20 805201500
805238390 NUT 20 805238390
805239158 NUT 20 805239158
8 RETARDER SETTING 1 228902316
9 WASHER 12 16 805338334
10 BOLT M12×40 10.9 1 805006287
11 BREATHE TUBE 1 228902321
12 MOTOR CONNECTION PLATE 1 228902076
13 SET 1 228702217
14 ANELLO DI SICUREZZA 32 1 805400068
805407844 Bracket 32 ​(Dacro) 1 805407844
15 MOLLA 1 228702503
16 BOLT 16 805046552
17 LOCKING PLATE 8 227002106
18 PRESSING PLATE 1 227002105
19 OIL SEAL 1 803164073
20 BEARING 1 800511395
21 O-RING 300×5.3 1 803199914
22 GREASE CUP 1 801138526
801103672 TAZZA OLIO 1 801103672
23 FRAME BEARING SET 1 228902070
24 OIL SEAL 1 801101753
25 BOLT M16×60 24 805004815
26 WASHER 16 48 805338246
27 RIGHT BEARING PEDESTAL 1 227002199
28 ORING 412×7 2 803302774
803164136 O-RING 412×7 2 803164136
29 BEARING 4 800516369
800557271 BEARING 4 800557271
31 BOLT 24 805006290
32 BEARING BLOCK 2 227001992
33 OIL PLUG 4 228700169
228700168 OIL PLUG 4 228700168
34 WASHER 30 4 805300055
35 ROLLER 1 228902371
36 WASHER 16 1 805300026
37 OIL LEVER BOLT 1 226802286
38 JACKET 2 227001554
39 TRANSMISSION SHAFT 1 229000865
41 LEFT BEARING HOUSING 1 228901602
42 PAPER GASKET 1 228700158
43 COVER 1 228700159
44 BOLT M12×30 54 805006412
45 ECCENTRICITY 1 228902675
46 ECCENTRICITY 1 228902686

=======================================

advantages

1. We supply both original and aftermarket products for you
2. From the manufacturer to the customer directly, saving your cost
3. In Time Delivery Time, with competitive shipping cost
4. Stable stock for normal parts
5. Professional and on time after service

packing

1. Standard export carton packaging
2. Carton packaging on wooden pallets
3. Customized packaging according to customer requirements

logistics and transportation

We will choose the most favorable logistics method for customers, and we can also specify the logistics method according to customer needs.

warehouse

We have built four spare parts warehouses in Xuzhou, Jining, Kunshan and Changsha to provide customers from all over the world with a variety of high-quality spare parts. We can basically ship self-provided spare parts within three days after confirming the order. If the spare parts need to be adjusted or processed, they will be shipped within 7-30 days.

our warehouse

our warehouse

Pack and ship

Pack and ship
