459321936 wiring harness for XCMG XP225H single drum roller

Short Description:

459321936 Wiring harness is an original dedicated circuit transmission component for XCMG XS225H single-drum roller. As the neural network of the whole equipment electrical system, it undertakes signal transmission, power supply conduction and circuit connection for the engine, hydraulic system, control system and instrument panel. It ensures accurate signal interaction and stable power supply of the roller during walking and compaction operation, supporting intelligent control and normal start-stop operation of the whole machine.

Send email to us

Product Detail

Product Tags

description

Part Number: 459321936
Applicable Model: XCMG XS225H Single-Drum Roller
Product Name: Wiring Harness
Structure: Integrated multi-circuit harness with customized waterproof plug-in
Main Material: High-temperature and oil-resistant wire core + flame-retardant and wear-resistant outer sheath
Core Function: Electrical power conduction, sensor signal transmission, equipment circuit integration
Working Feature: Anti-interference, low resistance, stable conduction, fast signal response
Environmental Adaptability: High and low temperature resistant, wear-resistant, waterproof and dustproof
Matching Parts: Engine electrical parts, controller, sensors, instrument assembly, power supply system

Specially suitable for XCMG XS225H single-drum roller. It is laid inside the chassis and engine compartment, adapting to long-term construction vibration, outdoor high and low temperature alternation, dust deposition, muddy water splashing and other harsh working conditions. It maintains stable circuit conduction and anti-interference performance under long-hour continuous operation.

Number	Parts Name	Quantity	Material Encoding
1	NUT	6	860152853
2	WASHER	6	860541593
3	CUSHION	6	860152854
4	VALVE COVER SYSTEM	1	860556022
5	VENTILATION DUCT	1	860508692
6	SCREW	2	860152856
7	COVER	1	860508693
8	HEXAGON SOCKET CYLINDRICAL HEAD SCREW	8	860152858
9	STUD	6	860152862
10	HEXAGON FLANGE BOLT	5	860152860
11	SLEEVE	5	860152861
12	HEXAGON FLANGE BOLT	2	860137726
13	SEALING TAPE	1	860508633
14	COVER	1	860508694
15	WIRING HARNESS	3	459321936
16	HEXAGON FLANGE BOLT	3	860152865
17	LIFTING EYE	1
18	HEXAGON FLANGE BOLT	2	800164546
19	SEAL RING	1	860152863
20	THERMOSTAT	1	860140379
21	CYLINDER HEAD GASKET	1	860564042

advantages

Adopts high-quality flame-retardant and oil-resistant wire materials, with strong environmental adaptability, effectively avoiding circuit aging, short circuit and open circuit caused by engine heat and oil pollution.
Integrated wiring design with reasonable circuit layout, clear classification of power lines and signal lines, effectively reducing signal crosstalk and ensuring accurate control data.
Equipped with high-precision waterproof and dustproof plugs, which have good sealing performance, preventing muddy water and dust from invading and causing poor circuit contact.
The outer protective sheath has excellent tensile and wear resistance, adapting to long-term vibration and friction of construction equipment, not easy to damage and break.
Strictly calibrated circuit resistance and signal transmission performance, stable power supply, no signal delay or drift, ensuring coordinated operation of the whole machine system.

maintenance & replacement tips

Regularly inspect the wiring harness surface for wear, aging, cracking and exposed wires to eliminate potential circuit failure risks in advance.
Check the plug-in connections and fixing straps frequently to prevent loose and virtual connections caused by long-term vibration.
Keep the harness layout area clean to avoid long-term accumulation of oil and dust accelerating line aging.
Avoid excessive stretching, bending and extrusion of the wiring harness during maintenance and operation to prevent internal wire breakage.
Use original 459321936 wiring harness to ensure stable circuit transmission and normal electric control operation of XS225H roller.

warehouse

We have built four spare parts warehouses in Xuzhou, Jining, Kunshan and Changsha to provide customers from all over the world with a variety of high-quality spare parts. We can basically ship self-provided spare parts within three days after confirming the order. If the spare parts need to be adjusted or processed, they will be shipped within 7-30 days.
