800381343 hood safety shaft XCMG XS135 road roller spare parts

Short Description:

Fit for XCMG road roller XS135, suitable for subgrade compaction and municipal road construction. Used to replace original hood safety shaft with bending deformation, worn & cracked pin hole and failed limiting function.

Send email to us

Product Detail

Product Tags

description

Part number: 800381343
Part name: hood safety shaft
Unit name: engine hood assembly
Applicable Models: XCMG XS135 vibratory road roller

Hood safety shaft is the safety limiting component for road roller engine hood. It supports and limits the opened engine hood to prevent accidental falling‑down and protect maintenance personnel. Shaft bending deformation, wear and cracked pin hole will lead to hood support failure. Sudden hood drop during overhaul may cause squeezing and collision risk.

Number	Parts Name	Quantity	Material Encoding
1	ENGINE HOOD	1	228305934
2	BOLT M10×30	12	805048006
3	THE RIGHT SAFETY DEVICE	1	228304559
4	BOLT	8	805048016
5	RIGHT GUARD PLATE	1	228305943
6	LEFT STOP PLATE	1	228305947
7	XS125 HOOD SAFETY SHAFT	1	800381343
8	GASKET	1	228305462

====================================

advantages

Shaft diameter, total length and pin‑hole position comply with original standard, good interchangeability for direct installation without secondary processing.
Integral quenching‑tempering treatment provides sufficient strength and stiffness to bear hood self‑weight impact and resist bending deformation.
Neatly processed pin‑hole ensures reasonable clearance with matched pin shaft for smooth opening‑closing without jamming.
Compact single‑piece part for easy on‑site maintenance replacement and short equipment downtime.

FAQ

Q: Can slightly bent safety shaft be reused after straightening?
A: Internal metal stress remains after correction, fracture may occur under load, direct replacement is recommended.
Q: Why hood cannot stay supported even with new safety shaft?
A: Check circlip installation, inspect deformation of hood hinge base and eliminate excessive fitting clearance.
