Road cold recycler XLZ2103 XLZ2303 road reclaimers

Short Description:

We supply XCMG and other good brands’ road cold recyclers, The models including XLZ230K, XLZ2103,XLZ2103E, XLZ2303, XLZ2303S, XLZ2305K, WR450D, WR500, WR530, WR600, WR700, WR800, WR2100.etc.


Product Detail

Product Tags

product description

Pavement cold recycling machine is an environmentally friendly and efficient road construction equipment designed and manufactured to adapt to urban and rural road construction. While milling and crushing the old asphalt pavement, stabilizers (cement, lime, water, etc.) are added during operation. In-situ mixing forms a new road base through shaping and compaction.

The machine applies to the mixing of stabilized soil at the base course and sub-base course of highways, city roads, plazas, wharfs and parking lots, as well as the construction of low-grade highways. The machine can be sued to mix up 1-class, 2-class, 3-class and 4-class soil and stabilize materials, and the building stones with a grain size of less than 40mm can be added into the mixing materials.

detail information

XCMG official XLZ2103

XLZ2103 road cold recycling machine is a multifunctional road maintenance machine mainly used for the upgrade operations of the used asphalt county and township roads as well as the in-site stabilized soil mixing operations.

1.Weichai turbocharged electronic injection diesel engine system, low emissions, low noise, low fuel consumption, fulfilling the requirements of Chinese Stage III emission standard. Three level power regulation control technology, allowing the machine working in the best fuel consumption area, more energy efficient.

2. Sprinkler system: automatic/manual control mode, user-friendly control, high spraying precision. Sprinkling water pump has self-priming function, can be seamless connected to all kinds of water wheel wagon.

3. Milling system: the grain size of milling material can be adjusted according to the rotor speed and operating speed, so as to ensure the uniformity of material granularity, meeting the requirements of different grading.

Optional rear wheel drive system adapt to complex conditions such as certain degree of muddy, slippery roads.

Model Unit XLZ2103
Engine Manufacturer Weichai engine
Engine model WP12.460N
Rated power /speed Kw/rpm 338/1900
Performance parameters Operating speed m/min 0~40
Travel speed Km/h 0~18.5
Gradeability % ≥20%(11.3°)
Ground clearance mm 400
Operating weight Kg 23800

XCMG XLZ2303 Road Cold Recycler

XLZ2303 road reclaimer is a set of multi-functional road maintenance equipment. It is mainly used for upgrading and reconstruction of old asphalt pavement. It is mainly used for mixing fllers, cement, limes and other objects with natural soil, So as to improve mechanical and physical properties of soil. It can be also used for milling damaged asphalt or asphalt concrete pavement with the thickness of 200mm and below.

Item Unit XLZ2303
Milling width mm 2300
Maximum milling depth mm 400
Cutter spacing mm 17
Diameter of milling wheel (with cutter) mm 1380
Cooling type Water-cooling
Model QSX15
The quantity of cylinder stator 6
Rated power kW 447
Engine speed rpm 2100
Oil consumption: Full load kg/h 98.3
Working speed km/h 0-2.5
Traveling speed km/h 0-10
Theoretical gradeability (working gear) % 40
Ground clearance mm 350
Front axle load kg 21000
Rear axle load kg 10000
Shipping weight kg 29500
Working weight kg /
Fuel tank L 1000
Hydraulic oil tank L 400
Water tank L 750
Voltage of electric system V 24
Machinery(length*width*height) mm 10193x3161x3450

 XCMG Official XLZ230K

XLZ230K road cold recycler is efficient, reliable and compact. Reasonable layout of tool bits facilitates high milling ability; Intelligent control of sprinkler system provides easy operation and high spraying precision; All wheel steering is flexible and easy to operate; The three-power curve of the engine realizes working in multiple working conditions, such as heavy load, light load and transitions, effectively guarantees the efficient operation of the engine, energy saving and environmental friendly.

Milling width 2300 mm
Maximum milling depth 450 mm
Tool spacing 30×2 mm
Number of tools 200/141
Milling wheel diameter (with tool) 1480 mm
Manufacturer MTU
Cooling method water cooling
Model OM502LA.E3A/3
Number of cylinders 8
Rated power 420kw
Engine speed 1800 rpm
Fuel consumption: full load 90.3 kg/h
Working speed 0-2.4 km/h
Walking speed 0-10km/h
Theoretical Gradeability (Work Block) 50%
Ground clearance 350
Front axle load 20000kg
Rear axle load 14000kg
Shipping weight 34000kg
Fuel tank 1200L
Hydraulic tank 400L
Water tank 400L
Electrical system 24V
Machinery (length×width×height) 9390×2995×3484mm

We supply XCMG and other good brands’ road cold recyclers, The models including XLZ230K, XLZ2103,XLZ2103E, XLZ2303, XLZ2303S, XLZ2305K, WR450D, WR500, WR530, WR600, WR700, WR800, WR2100.etc.

If you would like to know more products and details, please contact us!
